COMBINED SPRING BRAKE ACTUATOR

COMBINED SPRING BRAKE ACTUATOR DVT FPT DVT FPT

Brake bellows measurements can be made according to applied compression force, opening distance and test duration.

    INDUSTRIAL SECTORS OF USE

    TECHNICAL INFORMATION

    • Operating Voltage:  220 VAC or  220/380 VAC , 50 Hz.
    • Power consumption: 1 KVA’dır.
    • Unit performs horizontally .
    • Loading rate: 20 kN.
    • For invalid product there is a warning light.
    • Unit requires a workshop air supply.
    • Graphics printouts are available for test results.
    • Unit can be connected to PC.
    • Touch –screen.
    • Max.  stroke is 100 mm.
    • Items are archieved by product code and date.
    • Speed adjustment is between 0.5-500 mm/min.
    • Equipped with emergency stop button.
    • Fast reverse feature.
    • Programmed stop feature.
    •  ± % 0.5 sensitivity
    •  0,01 mm motion sensitivity

     TESTS PERFORMED WITH THE DEVICE

    • Compression force, distance and duration tests are performed.

    OPTIONAL ADDITIONS

    • Additional equipments for private experiments.
    • Optional length of movement.

    TEST SUBJECTS

    • Brake bellows.
    • Shock absorbers.

    APPROXIMATE DIMENSIONS AND WEIGHT

    • Width : 150 cm
    • Depth : 57 cm
    • Height : 143 cm
    • Weight : 233 Kg

    DOCUMENTS

    Specification Sheet

    ADDITIONAL INFORMATION

    The Combined spring brake actuator operates at 220 VAC or 220/380 VAC, 50 Hz, with a 1 KVA power consumption. It features a 20 kN compression capacity, ± %0.5 sensitivity, and 0.01 mm motion resolution. It offers 0.5-500 mm/min speed adjustment, 100 mm maximum stroke, and functions horizontally. Integrated with a PC and touch screen, it enables graphic printouts and item archiving by code and date. Equipped with emergency stop, programmed stop, and fast reverse.
